Sunday, February 17, 2013

Tesla Impulse technology explained by Bedini

Tesla placed a light bulb across a wire. When the impulses are correct, a node appears across this wire. That is where the voltage is. At the correct frequency, the free energy appears. (Remember Meyl's frequency)



It is meaningless to put parallel coils.

Put it in series.
The impulse is not AC or DC. It is just impulse or called it DC impulse at certain frequency rate. Create a node on this wire. Right At the tip of the node, take the energy of this wire.

Here is one might measure at the node of the capacitor and the battery.

Must send the impulse at the correct frequency.

The node appears with the impulses.



The positive energy comes off at capacitor and the negative energy comes off at the battery.


One can add as many series coil and shuttle the energy back and forth around the circuit. Put a cap, get the energy back to motor. Put a battery to get it charged.

How it becomes an energy pump?
The stationary magnet has a zero portion of the magnet. The absence of all gravitation. Particle aligned, oscillation stays. Energy enters on each sides. The energy from the vacuum, it stays permanent, perpetual. But we don't have a mechanism to tap this energy at this moment.



When the current catches up, you lose all your vacuum energy.

Scope shots on Bedini monopole motor

This is from the window motor scope shot. These back EMF (BEMF) cannot charge the battery. It is way below the 12V. The square pulse is the switching pulse.

Figure 1



H-wave from window motor but monopole triggering circuit.
Signal going down. Wheel turns faster. Battery can recharge more. Relieve current in the  loop? Stop the current so that nature can fill in.

Figure 2


More spikes. Convert the circuit from bi-polar to monopole.
AC generation in the loop

Figure 3



Spikes we want to capture
Figure 4


If a battery charged with negative energy will have hard time. It is eating positive energy.  The hole eats the electron until it is done then it will start to convert. Once negative holes are gone, it will go back up. Charge up. It happened in Jim Watson's battery. It could not  charged up. So we need the steps below(Figure 5)
  1. Get rid of the negative energy by depleting the battery
  2. Get rid of the holes
  3. Potentialize the ion to charge the battery, move to the other plate. It won't want to get into the holes.
Figure 5

Figure 6


Explaination to the wave form (Figure 7)
  1. Normal square pulse
  2. BEMF
  3. Impulse 300V
Many people think the coil reverses and the impulse is BEMF. The impulse is not BEMF. The  BEMF is always lower than the 12V. BEMF is 8V and not enough to charge the storage  battery. As the current raises, you lost all your vacuum input. I can show you the BEMF from  the window motor. It cannot charge anything. Take the impulse to charge the battery

Figure 7

We want this negative energy to charge the battery. (Figure 8)
Figure 8




Saturday, February 16, 2013

Bedini's Quotes on school girl monopole motor


The SG is a simple project, It was designed to give a basic understanding in Unidirectional pulses and how they can be used to charge a storage battery. but the Scalar functions of this circuit my not be understood by everybody. I have pointed out time and time Again the reason for not closing the loops in the system. My theory goes way beyond this group. The machine is a model, how you can effect space around that coil. All engineers think that a coil is nothing more then an electromagnet with a north and south pole, how very untrue. People think that the energy comes from the rate of change (di/dt). but how does the energy couple in the windings and where does it come from within the magnetic field. Most do not understand what a coil can be made to do if pumped with sharp gradients. For one thing the coil becomes a quadrupole field, (Gravity Wave Converter at 90 degrees). The reason for no closed loop around the coil. Then we must combine the true magnetic field with the north pole's around the wheel. However when using all north poles we have setup a set of Scalars around that wheel also, indicated by Q1, Q2, Q3, Q4, Q5 Q6 as shown in my drawings always.




These Scalars are just vectors but not uniform in level The Difference between these scalars Q1, Q2,Q3,Q4,Q5,Q6. sets up a bias voltage in the machine That subtracts from the generated output. The reason you see very little current on the output of the machine. The effect is that these Scalar Vectors > move in one direction to the battery. The lattice arrangement in the battery allows the Vectors to couple and form real EM current in that battery. As long as the Scalar component does not couple in The machine to form power Lenz's law does not apply, since we are not perfect in what we do a little leakage is possible in drag on the machine. The trigger can pump the Bloch wall, by doing this we build an energy pump.



Space around the coil or the vacuum ( Empty nothing) is like an electrical gas but the Scalars never couple in it, so you say we can't find anything. By taking the the Bloch wall where the two domains come together and Pumping that we open a window for Zero Point energy, very small in this machine but workable for this group. The energy always enters through this wall at right angles, the energy then couples in the windings of that coil. Producing what everybody terms as Back EMF, how wrong as Back EMF is never more then the source voltage under any condition. However the energy that does couple is at the exact level of potential of the electrical gas that surrounds you. Change the impedance of the coil you change the coupling effect. Now you have my answers, this is as far as I will go. Go sit and ponder it, you won't find it in a  textbook. The next step would be to take a quantum mechanics class. I had to make this machine  simple so anybody could build it. As I said you already have a free energy machine in front of you,  that little magnet, once charged it's forever unless you kill it cause a variance in the bloch wall and you have all the energy you want without movement. But you want to continue to move magnets Across coils the hard way to get energy, be my guest. - John B

  • Capturing of the spikes is considered radiant energy. Sharp transient in the spikes. Negative  energy comes from the battery. Once you generate the spikes to the battery. Negative effect to the battery because no heating in the battery. Steal that transient into the  battery.
  • Cannot put the secondary battery back to the front, they are different energy : positive and  negative. You can put any amount of battery on secondary side. Then, use an inverter to  charged the front.
  • No Lenz's Law. BEMF . It's free in monopole system. No counter BEMF to slow down the  motor. If we slow down the motor, we can't draw even more current.
  • Is pendulum system closed loop system? There are two loops not tied together. Out of phase  of each other. Comes in after. Charge the iron in the pendulum and trigger pulse takes place  later. About 22 deg after that. It's in between 2 magnets when the coil fires.
  • Imaginary pole between 2 magnetic north . Sharp pin point beams they come out and go  around. The south appears between the poles. The motor isn't running until it passes the  pole (south). Between this two magnets is where the coil fires. It's scalar south. Two north  poles pushed together to make a magnetic pin point beam. Not a good generator. No south pole, it's imaginary.

  • 2 different energies. One is driving the other is radiant used to charge the battery.
  • The south is about 23 deg. Since the motor is attractive, it is going to push away from  south. A zero between north and south. Zero. 23 with 8-pole motor. For 16 pole it is about  11.25 deg. The radiant charge precede the current flows. Capacitor causes heat. Charging, discharging, firing. (Charging iron=giving magnetic potential to the iron core.)

  • Charging iron, discharging iron, pole reverse and then firing.





  • When you hook three batteries up, two in series on the left and one on the right with negative terminal connected, it is not nothing.  There is a potential of 1.5V flowing. A wave of 3 and a wave of 1.5. A wave +3V and -3V. Expand the wave and put information. When it zeros out, it is going to contain all the information in the subtraction.

  • When I put a wave into the transistor, what is going to come out is the scalar function (impulse).


  • If I have a potential, generated with a spike of 300V and put it to the positive terminal. Take the invert transistor to the ground with some form of switch. When I closed the switch, the difference of potential is charging the battery. The 300V substracts the 12V. We want just potential and no current.
  • First, getting rid of mathematics involve with current. Second, hidden potential within subtraction.Whole idea is to hide all the information in the zero. Thus, this becomes a sharp transient.

  • If we expand the sharp transient, all we have is this hidden stuff.


  • I charge this iron at this potential. Now, magnet leaves, the iron wants to discharge and the pole in the iron flips. That is the correct phase for the transistor to fire. It is an attractive motor, instead of repulsion. What kicks the wheel away is this imaginary south.  No power in machine, not any torque been developed. Just triggering mechanism to catch this energy. The south triggering is to get the motion. What you really get is the hidden information after the cancellation (impulse). Then, send it to the battery and recharge.
  • Conventional circuit shorts it out with protection diode. In this design the diode send the spike out.



  • The pulse going negative, trying to be negative resistor. That cools it off. We want to capture the spike above the 12V.





  • Build a receiver that tune into pressure wave. It is wave beyond light.Capture the particle and convert into electron.

  • The current didn't get there. It's so fast. It's instantaneous. The meter sees the zero. (because) You  can't measure the current. Current slows. What control everything is the magnetic field. Is like pressure valve for the radiant.  The bigger the magnetic field the slower is the radiant. EM field is just a regulator to keep  everything pops.
  • You coil up a wire,  the magnetic field is collapsing, slowing down the frequency. Only a few frequency the radiant spike can pass through.




Notes on Howard Johnson Magnet


Bedini believes that there is two magnetic flux in bidirection.





Howard is trying to make asymmetrical magnet.





Magnet has been reconditioned to be asymmetrical.

There are 4 bloch walls in the magnet.


The hamel ball changes the magnetic flux.

Error in Bedini Pulse Charger US Pat 6677730


Few errors in Bedini Pulse Charger US PAT 6677730



  1. The +12V power source should not go to the H11D3 LED. This is supplied via the pin 11.
  1. The SG3524N does not have sink capability. Hence, the LED cannot bleeds off. Suggest to use another controller or add a bleeding resistor (e.g. 500 ohm) at pin 11 and pin 14.
  2. Pin 9 and Pin 1 need to be connected to get the EA line crossing the saw tooth wave.
  1. The 2K ohm resistor is pulled to ground. It doesn't seem to work well by connecting as diagram. Comment??
  1. The cap voltage is always lower than input voltage. May be the Vgs turns off when it charges up. Vgs 2-4V.
  1. Patent suggest 2k ohm between gate and drain of IRF260.(the 2nd drain?)

Notes on Kromrey Converter US Patent 3,374,376

The construction of Kromrey converter by Raymond Kromrey. US Patent 3,374,376 Mar 19, 1968:

  • The shaft has to be NON-MAGNETIC! Must be aluminium, brass. stainless steel.
  • 4 independent coils.
  • The middle ones are brushes.
















How it works:
The coils are locked by the magnetic fields. When you turn them, you break the magnetic fields and they discharged.

If the shaft is magnetic, the magnetic flux will look like this. This is the wrong magnetic flux that we don't want.



















The right magnetic flux is this.


















The flux direction



















The coil polarity is indicated as below.


















The bloch walls:

They are at the magnets between the north poles and south poles and also between the coils at the centre of the shaft.

















The energy comes in at the bloch walls. Sucking in energy and expelling energy through the coils.



















Unique feature:
Under load, it accelerates. The current goes down instead of going upward.
It is 120% efficiency. But, to get to be a free energy device, it has to be 300% or more. This is told by scientist who worked for government laboratory.

Maximum efficiency is 180% with this machine. It can  be used to charge battery. It can get up to 350% if the coils are parallel with low impedance.




















G-field stresses the gravity field.
The coils are hot but the surrounding is cold. Battery is very cold. Bulb is hot at ONLY one spot where the finger is touching. Energy out is cold electricity. It speeds up when charging battery. Fly wheel is used to quite the machine and smoothen the magnetic lock.


The magnets are the stator and coils are the rotor. Comparing to DC brushless fan, the magnets are the rotor and the coils are the stator. Meaning the DC fan should be rotated by another motor and make the fan a generator.

Saturday, February 2, 2013

Pure magnet fan motor

Kanál uživatele Deirones from Czech has a website that publish the motor construction with magnets. However, I have not been able to produce the similar effect. The is no sufficient info on the pole of the magnet. But remembering Hamel motor effect, there is a tendency of having a vortex at the center with all north pole pointing inside. This is the closest theory that I can think of.
